The Defibtech Lifeline VIEW AED is a high-tech, durable device. It has a full-color display and ECG functionality. It’s a versatile tool. It’s a top choice for medical pros, first responders, and high-stress workers in utilities and sports. Consider the Defibtech Lifeline AUTO or the HeartSine PAD 450P, which are both affordable options. They perform well and are high quality.
Summary of Defibtech Lifeline VIEW
- Price Range: $1,880-$2,899
- Durability: IP55
- Features: ECG display optional, available in fully-automatic, aviation option, electrode pads self-test, converts AED to trainer, option for stand-alone trainer sold separately
- Battery Lifespan: 4 years
- Electrode Pad Lifespan: 2 years
Defibtech Lifeline VIEW features
The Defibtech Lifeline VIEW AED is one of the most durable, feature-rich AEDs. It is made of high-quality materials for reliability and performance.
Device features
- Rugged and durable: Made with the same material as a football helmet.
- Water, dust, and crush resistant up to 1,000 lbs.
- For high-vibration settings, including planes, helicopters, and boats. An aviation version is available.
- The ECG version can switch to an ECG display. It’s ideal for professional responders and those with advanced training.
Device specifications
- Model: DBP-2003, DDU-2450 (ECG version)
- Size: 7.3 x 9.5 x 2.3 inches (18.5 x 24 x 5.8 cm)
- Weight: Less than 3 lbs (1.4 kg) with battery
- Ingress Protection Rate: IP55; water, dust, and crush resistant (up to 1,000 lbs)
- Operating temperature: 0o to 50oC (32o to 122oF)
Battery specifications
- Battery power: 12 v, 2800 mAh
- Battery capacity: 125 shocks or 8 hours of continuous operation
- Battery life: 4 years
- Type: Lithium/Manganese Dioxide disposable, recyclable, non-rechargeable.
- Visible and audible indicators will notify users of low battery.
- System integrity test on battery inspection.
- The user may also initiate unit and battery pack system tests.
Pads specifications
- Adult and pediatric pad options are available.
- Part #s: DDP-100, DDP-200P
- The system tests pre-connected pads daily during the Pad Presence self-test.
- Pad Placement: Adult – Anterior/Anterior and Child/Infant – Anterior/Posterior
- Cable length of pads: 48 in (122 cm)
- The device includes disposable, pre-connected, self-adhesive electrodes designed for single use. It has a non-polarized design with an integrated cable and connector for easy use.
- Dispose of and replace pads after use or at the end.
Device performance and reliability
The same expert engineers designed the Defibtech Lifeline and Lifeline AUTO. Their work is behind the Defibtech Lifeline VIEW AED. It surpasses the AHA’s performance standards. This gives rescuers confidence that victims are receiving reliable care.
In 2020, a safety alert was issued for the Lifeline VIEW, Lifeline ECG, and ReviveR VIEW devices. For more info or to check for device changes, see the Defibtech 2020 AED Safety Alert.
Defibtech certifications
In February 2021, Tech Top 40 named Defibtech a top five fast-growing life science company. In May 2011, the Defibtech Lifeline VIEW won a Silver Award for medical equipment at the 24th annual Excellence in Design Awards.
In March 2011, the Defibtech Lifeline VIEW won a Medical Design Excellence Award. This competition celebrates innovation in medical device design that improves healthcare.
The company has also earned recognition for several notable achievements:
- Spark International Design Award (November 2012)
- Exporter of the Year Award (March 2013)
- American Business Award (June 2010)
- CQIA Innovation Prize (July 2010)
- IDSA Design of the Decade (December 2010)
Explore the full list of Defibtech’s awards and accomplishments.
Defibtech Lifeline VIEW cost analysis
The Defibtech Lifeline VIEW is a premium AED. It costs $1,880 to $2,899 and is for medical professionals and first responders. Its advanced ECG capabilities, durable construction, and high-quality color display justify the investment. Replacement parts, like adult and pediatric electrode pads and batteries, cost extra. They usually range from $70 to $210.
The device needs little upkeep. Replace the pads every two years. The batteries last five to seven years, depending on usage and the status indicator. These durable accessories lower maintenance costs. So, the device is a cost-effective choice over time.
Use-Case Analysis
The Defibtech Lifeline VIEW AED is ideal for medical professionals. It is suitable for urgent care in tough settings, such as during patient transport or in noisy places.
- Ambulance
- Cop cars
- Fire trucks
- Construction sites
- Factories
- Fitness centers
- Arenas
These environments suit the Defibtech Lifeline VIEW. But, only trained users should operate the ECG feature. They must know cardiac rhythms and manual defibrillation.
Local AED Regulations
Many states have laws that hold AED owners accountable. The requirements vary by location. Schools, gyms, and large facilities must have an AED on-site. Also, corporate industries must follow OSHA or federal rules. This includes AED use and CPR training guidelines.
Businesses can reduce liability by following state AED laws and defibrillator policies. Utilizing program management solutions further supports legal protection and adherence to regulations.
Keeping up with changes in AED regulations is essential, as laws can evolve at a rapid pace. Use reliable sources to stay updated on new AED laws.
- AED Law Center
- Public Access Defibrillation (PAD) State Law Fact Sheet
- AED Laws and Legislation Page
- Casetext
- Find Law
How to use the Defibtech Lifeline VIEW AED.
Unlike other AEDs that only give verbal instructions, the Defibtech Lifeline VIEW has a large, full-color screen. It is interactive. It guides you with visuals, making it easier to follow during emergencies.
The features outlined below provide step-by-step guidance on using the device:
- The full-color interactive screen provides clear prompts, both visual and vocal. It guides you through CPR, rescue breathing, and defibrillation.
- It has full-text prompts and detailed voice instructions. It’s very effective, even in noisy environments.
- A built-in metronome will assist with your compression rates during CPR.
- Real-time protocol selection lets rescuers switch CPR methods. They can use CPR. It can be only compressions, or it can include rescue breathing. Both ensure effective emergency care.
- The one-touch status screen simplifies maintenance. It shows the readiness of both pads and batteries.
- Built-in video gives easy step-by-step guidance during maintenance.
- Proactive reporting tracks end dates. It alerts you when pads or batteries are near their lifespan.
- The device resists water, dust, and crushing up to 1,000 lbs. For extra protection, we tell using a soft carrying case.
Watch the full Defibtech Lifeline VIEW AED Overview in the video below.
Defibtech Lifeline View saves stories.
This story shows how the Defibtech Lifeline VIEW AED has saved lives. Officer John O’Neil responded to two emergencies months apart. He used the device to stabilize victims until paramedics arrived. Days before O’Neil’s second call, Officer Christopher Prell used the same AED to stabilize a patient. This showed that it could save lives.
Defibtech defibrillator manufacturer information
Defibtech’s history reflects its mission. It aims to improve survival rates from sudden cardiac arrest. In 1999, Yale grads Dr. Glenn Laub and Dr. Gintaras Vaisnys founded the company. It aimed to make AEDs affordable and accessible to individuals and small businesses.
Defibtech’s journey began with the FDA’s 2002 approval of the Lifeline AED. The Lifeline VIEW AED followed it. By 2007, it was one of North America’s fastest-growing medical equipment companies. The company thrives. The company is based in Guilford, CT. It manufactures products in Branford and North Branford.
Defibtech’s Lifeline AED has been a trusted choice worldwide, with over 400,000 units. The Lifeline VIEW AED has an eight-year warranty from the sale date. The warranty covers its battery for up to four years or until its printed end date. Manufacturers warrant single-use accessories, like electrode pads, until they are no longer used.
FAQs
What is the purpose of the Lifeline VIEW screen?
The Defibtech Lifeline VIEW AED has a full-motion video screen. It shows text prompts that complement the audio instructions. These prompts guide users during resuscitation, which helps in noisy places. The device aids hearing-impaired or non-English-speaking rescuers and ensures support for all users.
What is the difference between the Lifeline VIEW and the Lifeline VIEW with ECG?
The Defibtech Lifeline VIEW/ECG has all the features of the VIEW model. It adds a mode to view the patient’s ECG. This manual mode is for medical professionals only. They must train in cardiac rhythm recognition and manual defibrillation.
What are the two operating modes of the Defibtech Lifeline ECG?
The Defibtech Lifeline VIEW/ECG has an AED mode. It provides high-resolution video instructions and CPR coaching. It also has an ECG mode, which shows ECG data and events using 3-lead electrodes.
What allows users to operate an aircraft’s Defibtech Aviation VIEW/ECG model?
The Defibtech Lifeline VIEW/ECG Aviation model has a TSO-C142 battery and can operate at up to 15,000 feet. The FAA has approved it under a Technical Standard Order (TSO) certificate. This means it meets strict standards for use on planes.
Conclusion
The Defibtech Lifeline VIEW/ECG is a reliable, innovative AED. It has advanced features to help responders in emergencies. Its durable design, specialized models, and FAA certifications make it versatile. It can save lives in any environment. Its ease of use and advanced features make it a top choice for emergency preparedness.
